Acu-Drain Piping Solutions
Drainage Solutions

ACU-DRAIN: Greasy, Trade and Laboratory Waste, Siphonic Stormwater and Sewer Pipelines

Acu-Drain HDPE presents a comprehensive drain, waste, and vent system comprising pipes and fittings crafted from high-density polyethylene (HDPE).

This versatile drainage pipe solution is extensively employed in commercial and industrial constructions to efficiently channel wastewater to designated points within buildings. Acu-Drain poly pipes find application in various scenarios, including siphonic drainage systems, greasy laboratory waste disposal, general plumbing, and stormwater drains.

Joining Acu-Drain poly pipes is seamless with EF drainage fittings, readily available from Acu-Tech.

Particularly in regions with high rainfall, such as the Pilbara area in W.A., and urban locales with expansive concrete or asphalt surfaces prone to rainwater accumulation, poly drainage pipes are the preferred choice.

Unlike HDPE pressure pipes, drainage pipes operate under non-pressure conditions, resulting in thinner walls for Acu-Drain pipes. This characteristic renders them remarkably lightweight and easy to cut, facilitating swift installation.

With a commitment to exceptional service and substantial inventory, Acu-Tech delivers competitive pricing, leveraging its status as a leading manufacturer of PE drainage pipes.

The Acu-Drain HDPE pipe system offers the following advantages:

  • A complete product range from 50 mm to 315 mm, and larger sizes are be made to order.
  • High resistance to chemicals, as well as organic and inorganic solvents.
  • Easy to join lengths of pipe with Acu-Drain electrofusion drainage fittings.
  • High temperature resistance: HDPE can handle temperatures from -40°c to +95°c.
  • Extremely resistant to mechanical stress due to high elasticity, flexibility and impact resistance. This makes HDPE particularly suitable for installation in unstable ground.
  • Fully corrosion resistant, Acu-Drain polyethylene pipe is also resistant to build up or scaling due to its smooth inner surface and chemical properties.
  • Prefabricated poly pipe spools can be made to order with bends, tees or flanged ends to suit your requirements.
  • Comprehensive product and installation training of welding procedures and equipment.
  • Sales, hire, repair and calibration of poly welding equipment, particularly for poly drainage pipe welders.
  • Manufactured to AS/NZS 4401 “Plastics piping systems for soil and waste discharge (low and high temperature) inside buildings – Polyethylene (PE)” and AS/NZS 5065 “Polyethylene pipes and fittings for drainage and sewerage applications”
PE drainage pipe is available in the following sizes (All SDR26 unless otherwise noted):
  • Acu-Drain HDPE drainage pipe DN50 mm 5m length (DBK05026005).
  • Acu-Drain HDPE drainage pipe DN56 mm 5m length (DBK05626005).
  • Acu-Drain HDPE drainage pipe DN63 mm 5m length (DBK06326005).
  • Acu-Drain HDPE drainage pipe DN75 mm 5m length (DBK07526005).
  • Acu-Drain HDPE drainage pipe DN90 mm 5m length (DBK09026005).
  • Acu-Drain HDPE drainage pipe DN110 mm 5m length (DBK11026005).
  • Acu-Drain HDPE drainage pipe DN125 mm 5m length (DBK12526005).
  • Acu-Drain HDPE drainage pipe DN160 mm 5m length (DBK16026005).
  • Acu-Drain HDPE drainage pipe DN200 mm 6m length (DBK20026006).
  • Acu-Drain HDPE drainage pipe DN200 mm 6m length (DBK20033006) (SDR33).
  • Acu-Drain HDPE drainage pipe DN250 mm 6m length (DBK25026006).
  • Acu-Drain HDPE drainage pipe DN250 mm 6m length (DBK25033006) (SDR33).
  • Acu-Drain HDPE drainage pipe DN315 mm 6m length (DBK31526006).
  • Acu-Drain HDPE drainage pipe DN315 mm 6m length (DBK31533006) (SDR33).

Other size pipe can be manufactured to order. Contact us today!

Download the Acu-Drain Drainage Catalogue: Acu-Tech HDPE Drainage Catalogue
